Air Handling Units (AHUs) tend to have their airflow configuration in a horizontal direction, but there are some instances where a vertical AHU is needed instead, depending on the area it will be installed in. This was the case for a medical technology company, located in western UK, who were planning on upgrading their cleanroom ventilation system.

AirCraft Air Handling got to work with assisting in the design of a bespoke arrangement for this specific vertical AHU. It needed to function in an unclassified cleanroom, filtering dust and external pollutants out whilst controlling the humidity and temperature of the supply air. The clean room in question also required regulated air pressure for optimum performance. Our design team worked closely with the cleanroom contractor to finalise the specifications for an up-flow air AHU, which was delivered to the site in a modular format.
